Arizona Metals Corp. (TSX:AMC) (OTCQX:AZMCF) is pleased to announce that the first hole (KM-23-104) drilled at the Western Target of the Kay Mine Project intersected 16 metres of stringer to semi-massive sulphide mineralization, including visible copper sulphide (chalcopyrite) and zinc sulphide (sphalerite). The VMS mineralization occurs within a broader interval of syn-mineral quartz-carbonate veining accompanied by sulphide minerals (pyrite, pyrrhotite, sphalerite, chalcopyrite, and arsenopyrite) and anomalous zinc and copper readings from onsite portable XRF. This hole ended in sulphide-bearing core but was stopped at 888 metres downhole due to separated drill rods. Hole 104 has been submitted for assay and results are pending. A new branch hole, KM-23-104A, has been wedged up-hole in order to continue testing this new zone of mineralization (Fig. 2).



The Company believes that KM-23-104 intersected mineralization on the limb of an anticline along the prospective felsic host-rock horizon identified on the project. A drill rig is being moved to pad W2 to test for mineralization along strike to the north of this prospective stratigraphic horizon (Fig. 1). A hole here, KM-23-107, will commence shortly.



Marc Pais, CEO, commented “Intersecting such a broad interval of VMS mineralization in our very first hole at the Western Target is extremely gratifying, and is another step towards confirming our thesis that mineralization extends on our claims well beyond the footprint of the Kay Mine Deposit. We have observed mineralization and alteration in this first hole that is similar to what we see in proximity to massive sulphide mineralization at the Kay Mine Deposit. With this first successful hole to guide our targeting, we are moving a second drill to the Western Target to accelerate our testing of the new mineralized zone.”



Mark HanningtonTechnical Advisor, commented The assemblage of chlorite-pyrite-pyrrhotite-sphalerite encountered in the first hole at the Western Target is classic stringer mineralization typically seen at the margins of VMS deposits. Due to deformation, stringer mineralization is usually strongly transposed into the cleavage, so any associated massive sulfides may be along strike or even detached from the stringers (parallel to the axial plane of the folds). This is very similar to the deformed stringer mineralization in a number of large VMS deposits.”



Table 1. Summary drill logs of mineralized intervals in hole KM-23-104



From (m) To (m) Interval (m) Description
240.8 244.9 4.1 Felsic graphite schist with weak stringers of pyrite and trace chalcopyrite
535.5 536.1 0.6 Semi-massive arsenopyrite
547.0 552.8 5.8 Felsic graphite schist with weak stringers of pyrite and trace chalcopyrite
569.1 571.5 2.4 Felsic graphite schist with weak stringers of pyrrhotite and trace chalcopyrite
571.5 572.1 0.6 Semi-massive pyrite
578.7 579.7 1.1 Felsic graphite schist with patchy disseminated pyrrhotite
825.1 858.0 32.9 Felsic to intermediate volcaniclastics and volcanic breccia containing quartz-carbonate-sulfide veins and laminated sulfides (pyrite, pyrrhotite, sphalerite, chalcopyrite, arsenopyrite)
858.0 874.2 16.2 Coarse felsic-intermediate volcaniclastics and volcanic breccia with semi-massive, stringer, and disseminated pyrite and pyrrhotite with trace sphalerite and chalcopyrite, black chlorite, and intense quartz-carbonate alteration.
874.2 887.7 13.6 Felsic to intermediate volcaniclastic and volcanic breccia containing quartz-carbonate-sulfide veins and laminated sulfides (pyrite, pyrrhotite, sphalerite, chalcopyrite, arsenopyrite)




Recent surface sampling also returned up to 8.6% Cu in oxidized outcrop samples near the surface projection of the drilled mineralization (Figures 2 and 3). Another surface sample contained 3.3% Cu along the prospective stratigraphic horizon approximately 700 m north of drill pad W1. These samples are further confirmation of broadly distributed mineralization on the Kay project.



Arizona Metals is fully-funded (with $53 million in cash at Dec 31, 2022) to complete the remaining 2,900 meters planned for the Phase 2 program at Kay Mine Deposit (budgeted at $1.2 million) as well as an additional 76,000 meters in the Phase 3 program (budgeted at $32 million), which will be used to test the numerous parallel targets heading west of the Kay Mine Deposit, as well as possible northern and southern extensions.



Table 2. Full results of Phase 2 Drill Program at the Kay Mine Deposit, Yavapai County, Arizona.



Analyzed Grade Analyzed Metal Equivalent Metal Equivalent
Hole ID From m To m Length m Cu % Au g/t Zn % Ag g/t Pb % Cu eq % Au eq g/t Zn eq% Cu eq % Au eq g/t Zn eq%
KM-21-17 429.5 449.9 20.4 1.81 1.10 1.20 21.2 0.17 3.14 5.15 8.18 2.73 4.47 7.10
including 429.5 434.0 4.6 4.61 1.73 1.91 29.1 0.24 6.68 10.96 17.39 5.92 9.70 15.39
including 432.7 434.0 1.4 0.52 6.81 8.29 40.0 1.10 8.41 13.79 21.89 6.76 11.09 17.60
KM-21-17 504.4 505.4 0.9 1.19 4.73 0.05 9.0 0.00 4.17 6.83 10.84 3.20 5.24 8.31
KM-21-18 404.3 429.8 25.5 0.35 0.86 1.71 15.8 0.23 1.71 2.80 4.44 1.43 2.35 3.72
including 408.6 410.6 2.0 0.50 2.22 7.25 64.4 0.82 5.33 8.74 13.87 4.51 7.39 11.72
including 424.9 427.3 2.4 1.60 2.59 3.16 18.0 0.52 4.66 7.64 12.12 3.92 6.43 10.21
KM-21-18A 391.4 423.8 32.5 1.09 0.62 1.25 17.7 0.15 2.13 3.48 5.53 1.85 3.04 4.82
including 393.3 395.8 2.4 9.57 2.83 2.72 40.9 0.28 12.73 20.87 33.12 11.36 18.63 29.56
KM-21-19 377.8 378.3 0.5 3.39 5.59 6.83 128.0 0.63 10.58 17.34 27.52 8.81 14.44 22.92
KM-21-20 442.7 443.6 0.9 2.56 0.52 3.52 18.5 0.14 4.40 7.22 11.45 3.98 6.52 10.34
KM-21-20 456.0 458.1 2.1 1.49 0.35 0.14 6.0 0.04 1.81 2.97 4.71 1.63 2.66 4.23
KM-21-21 452.6 495.5 42.8 0.80 0.78 1.52 15.1 0.15 2.01 3.29 5.22 1.73 2.83 4.49
including 488.7 493.5 4.8 0.26 2.50 6.13 27.6 0.54 4.48 7.34 11.65 3.74 6.13 9.73
KM-21-21A 422.0 431.4 9.4 1.17 0.57 2.25 8.6 0.36 2.53 4.15 6.58 2.25 3.68 5.85
KM-21-21A 439.1 502.1 63.0 0.45 1.28 3.14 58.8 0.77 3.08 5.04 8.00 2.57 4.21 6.67
including 465.0 481.9 16.9 0.52 2.45 4.05 80.9 0.99 4.43 7.26 11.53 3.62 5.94 9.42
KM-21-22 679.4 682.8 3.4 0.79 0.95 0.06 12.0 0.01 1.49 2.44 3.87 1.23 2.01 3.20
KM-21-23 394.4 401.4 7.0 0.36 0.93 1.94 13.5 1.17 2.05 3.35 5.32 1.73 2.84 4.51
KM-21-23 438.6 459.2 20.6 0.17 1.18 1.93 27.8 0.37 1.94 3.17 5.03 1.58 2.59 4.11
KM-21-24 501.2 592.1 90.8 0.45 1.33 3.42 44.6 0.41 3.02 4.95 7.86 2.53 4.15 6.59
including 501.2 521.7 20.4 1.34 1.70 6.35 113.1 0.66 5.86 9.60 15.24 4.99 8.18 12.99
including 520.9 521.7 0.8 1.75 16.50 9.55 574.0 1.22 20.31 33.29 52.82 15.57 25.52 40.50
including 575.9 592.1 16.2 0.16 2.50 6.00 44.4 0.79 4.51 7.40 11.74 3.75 6.14 9.74
including 588.7 590.4 1.7 0.47 9.98 23.70 18.2 0.13 15.84 25.96 41.20 13.21 21.65 34.36
KM-21-25 662.6 741.3 78.6 1.41 2.33 2.79 43.4 0.35 4.33 7.10 11.26 3.61 5.92 9.40
including 663.2 672.7 9.4 8.06 1.84 1.31 92.3 0.15 10.45 17.13 27.18 9.30 15.24 24.19
including 693.0 703.9 11.0 0.68 6.28 10.40 99.7 1.17 9.56 15.66 24.86 7.79 12.77 20.27
KM-21-25A 654.7 719.9 65.2 1.04 1.94 2.15 18.9 0.18 3.25 5.32 8.44 2.71 4.43 7.04
including 655.5 662.8 7.3 3.66 2.09 1.85 30.2 0.21 5.93 9.73 15.44 5.17 8.47 13.44
including 710.8 716.9 6.1 2.72 7.95 3.73 37.4 0.31 9.37 15.36 24.38 7.52 12.33 19.56
KM-21-25B 647.2 648.9 1.7 0.13 0.58 2.41 62.1 0.64 2.04 3.35 5.31 1.70 2.79 4.42
KM-21-25B 655.6 659.9 4.3 0.93 0.91 0.91 25.3 0.19 2.07 3.40 5.40 1.75 2.88 4.56
KM-21-25B 666.0 667.8 1.8 0.60 0.72 2.98 33.5 0.43 2.55 4.18 6.63 2.20 3.61 5.72
KM-21-25B 673.3 674.7 1.4 0.08 2.10 2.39 23.0 0.33 2.53 4.15 6.58 2.01 3.29 5.23
KM-21-25B 681.2 682.6 1.4 0.09 1.54 2.98 11.0 0.35 2.34 3.83 6.08 1.93 3.16 5.01
KM-21-26 506.7 582.8 76.0 0.79 1.61 4.23 32.7 0.54 3.78 6.19 9.83 3.21 5.27 8.36
including 511.1 526.1 14.9 0.73 1.78 9.68 43.3 0.77 6.05 9.92 15.74 5.26 8.63 13.69
including 573.8 582.8 9.0 4.02 6.06 3.32 18.2 0.19 9.18 15.04 23.87 7.64 12.52 19.87
KM-21-27 706.8 738.2 31.4 1.58 0.16 0.69 9.0 0.06 2.03 3.33 5.28 1.85 3.03 4.80
KM-21-27 764.4 777.4 13.0 2.85 0.48 0.17 8.5 0.02 3.29 5.39 8.55 2.97 4.87 7.73
KM-21-27A 666.3 769.4 103.1 0.79 1.06 1.90 35.8 0.42 2.54 4.17 6.62 2.15 3.52 5.59
including 666.3 687.0 20.7 3.21 1.39 1.26 19.4 0.20 4.74 7.77 12.33 4.18 6.84 10.86
including 706.4 724.6 18.3 0.69 2.69 4.70 92.2 1.21 5.13 8.41 13.35 4.22 6.91 10.97
including 752.9 763.8 11.0 0.07 1.07 4.68 95.3 0.98 3.49 5.73 9.09 2.92 4.78 7.59
KM-21-27B 665.8 762.9 97.1 1.31 1.62 3.21 31.7 0.40 3.88 6.35 10.08 3.31 5.42 8.61
including 702.0 723.0 21.0 0.87 4.56 9.03 81.5 1.10 8.01 13.13 20.83 6.63 10.87 17.25
including 723.0 738.2 15.2 4.97 0.36 0.42 18.7 0.05 5.51 9.03 14.33 5.04 8.26 13.11
KM-21-28 640.7 694.9 54.3 1.87 2.85 5.03 29.4 0.70 5.93 9.72 15.43 5.04 8.26 13.12
including 660.2 671.6 11.4 0.54 4.29 9.30 32.2 1.17 7.24 11.87 18.84 6.04 9.89 15.70
including 681.1 689.0 7.9 4.39 9.47 10.34 93.1 2.41 15.42 25.27 40.10 12.80 20.98 33.29
including 690.4 692.6 2.2 16.06 0.82 0.06 55.8 0.01 17.02 27.90 44.28 15.62 25.61 40.64
KM-21-29 393.0 393.8 0.8 0.43 1.54 4.92 9.0 0.21 3.38 5.54 8.79 2.89 4.74 7.53
KM-21-30 264.9 267.9 3.0 1.18 0.02 0.01 1.5 0.00 1.21 1.98 3.15 1.12 1.83 2.91
KM-21-32 316.4 320.0 3.7 1.84 1.29 2.47 38.5 0.30 3.95 6.47 10.27 3.41 5.60 8.88
KM-21-32 342.9 345.9 3.0 0.67 0.52 2.70 13.0 0.15 2.16 3.54 5.62 1.90 3.12 4.95
KM-21-32 358.9 368.4 9.4 0.60 1.47 1.99 45.7 0.35 2.70 4.42 7.01 2.22 3.63 5.76
KM-21-33 171.3 172.5 1.2 3.79 0.45 0.21 63.0 0.17 4.69 7.68 12.19 4.19 6.86 10.89
KM-21-34 299.3 303.9 4.6 0.29 1.69 0.94 46.3 0.26 2.12 3.47 5.50 1.65 2.70 4.29
KM-21-34 309.7 310.9 1.2 2.27 0.56 1.55 19.9 0.08 3.38 5.54 8.80 3.03 4.96 7.87
KM-21-35 609.6 615.1 5.5 0.92 1.26 1.71 57.7 0.02 2.80 4.60 7.29 2.33 3.82 6.06
including 609.6 613.0 3.4 1.39 1.69 1.98 54.0 0.01 3.61 5.92 9.40 3.03 4.96 7.87
KM-21-38 406.5 407.8 1.4 0.60 1.08 9.41 4.0 0.25 4.96 8.13 12.90 4.42 7.24 11.49
KM-21-38 467.4 476.1 8.7 0.09 1.73 3.87 61.1 1.22 3.38 5.55 8.80 2.78 4.56 7.23
including 470.0 475.2 5.2 0.12 2.44 5.68 87.5 1.79 4.88 8.01 12.71 4.02 6.59 10.46
KM-21-40 589.8 613.8 24.0 4.98 0.61 0.98 23.4 0.45 6.01 9.86 15.65 5.46 8.95 14.21
including 589.8 597.9 8.1 7.63 0.43 0.39 27.1 0.17 8.30 13.60 21.58 7.61 12.47 19.78
KM-21-40 627.9 680.8 52.9 0.47 2.91 3.40 35.7 0.40 3.93 6.44 10.22 3.17 5.20 8.25
including 641.1 648.3 7.2 1.15 7.66 8.27 88.5 0.92 9.90 16.23 25.76 7.95 13.03 20.68
including 670.3 674.1 3.8 1.53 10.89 9.47 24.6 0.61 12.15 19.91 31.59 9.69 15.88 25.19
KM-21-41 462.6 559.3 96.7 1.04 1.54 2.66 40.8 0.35 3.41 5.59 8.86 2.87 4.71 7.47
including 503.2 514.2 11.0 0.99 5.34 8.17 106.3 1.63 8.59 14.08 22.35 7.02 11.51 18.26
including 546.7 558.1 11.4 5.86 5.83 3.24 185.4 0.04 12.14 19.90 31.58 10.15 16.64 26.40
including 553.1 556.9 3.8 7.11 9.55 5.70 505.8 0.09 19.16 31.41 49.84 15.62 25.59 40.62
KM-21-42 803.5 810.3 6.9 0.05 1.60 1.58 64.3 0.35 2.22 3.64 5.78 1.73 2.83 4.49
KM-21-42 835.5 839.7 4.3 0.63 2.46 2.15 21.7 0.21 3.18 5.20 8.26 2.56 4.20 6.67
KM-21-42 853.7 854.7 0.9 0.11 1.63 2.88 28.0 0.40 2.52 4.13 6.55 2.05 3.37 5.34
KM-21-42A 786.7 787.6 0.9 0.03 3.61 2.18 17.0 0.70 3.36 5.51 8.74 2.58 4.22 6.70
KM-21-42A 805.4 811.1 5.6 6.17 0.92 0.18 39.5 0.01 7.12 11.68 18.53 6.43 10.54 16.72
including 807.0 808.9 2.0 10.72 0.87 0.11 61.8 0.00 11.79 19.32 30.66 10.74 17.60 27.93
KM-21-42A 840.9 877.2 36.3 0.55 0.62 1.35 10.7 0.13 1.56 2.56 4.06 1.34 2.20 3.49
KM-21-42B 808.0 811.2 3.2 0.29 2.06 5.77 63.0 0.94 4.47 7.33 11.63 3.74 6.13 9.72
KM-21-42B 816.9 819.9 3.0 2.31 0.66 1.23 16.0 0.15 3.35 5.49 8.71 2.99 4.90 7.77
KM-21-42B 835.5 840.8 5.3 0.02 0.73 2.93 13.5 0.24 1.75 2.87 4.56 1.49 2.45 3.88
KM-21-42C 849.2 877.4 28.2 3.81 0.47 0.29 12.5 0.09 4.32 7.08 11.24 3.93 6.44 10.23
including 849.2 854.7 5.5 14.57 0.66 0.16 37.5 0.03 15.34 25.14 39.89 14.11 23.12 36.70
including 863.8 869.4 5.6 2.29 1.17 0.59 13.1 0.25 3.39 5.55 8.81 2.96 4.85 7.70
including 874.8 877.4 2.6 2.83 0.26 0.03 7.2 0.01 3.06 5.02 7.96 2.80 4.59 7.28
KM-21-42C 886.1 889.1 3.0 0.87 0.88 0.50 5.2 0.05 1.65 2.71 4.30 1.40 2.30 3.65
KM-21-43 583.7 607.1 23.4 0.39 0.25 3.68 3.1 0.02 1.98 3.25 5.15 1.79 2.93 4.65
including 598.9 599.8 0.9 0.50 0.18 11.30 3.0 0.03 4.99 8.17 12.97 4.56 7.48 11.87
KM-21-43 616.0 633.1 17.1 1.81 0.17 0.14 8.2 0.03 2.04 3.34 5.31 1.86 3.05 4.84
including 631.2 633.1 1.8 6.30 0.61 0.09 25.0 0.01 6.91 11.32 17.97 6.30 10.32 16.38
KM-21-44 353.4 377.3 23.9 0.34 0.97 2.52 18.3 0.33 2.12 3.47 5.50 1.79 2.93 4.65
including 354.0 356.6 2.6 0.23 2.14 7.97 38.9 0.68 5.06 8.29 13.15 4.30 7.05 11.19
KM-21-45 459.6 463.0 3.4 0.32 0.62 6.63 82.3 0.87 4.10 6.71 10.65 3.55 5.82 9.24
including 461.2 462.1 0.9 0.15 1.23 16.90 182.0 2.50 9.39 15.38 24.41 8.17 13.39 21.26
KM-21-46 350.4 362.9 12.4 0.66 2.61 3.69 40.6 0.39 4.08 6.69 10.61 3.34 5.48 8.70
including 350.4 353.3 2.8 0.77 5.19 6.83 107.0 0.72 7.58 12.42 19.70 6.11 10.01 15.88
KM-21-47 433.9 435.9 2.0 0.16 1.88 9.28 138.7 2.17 6.46 10.58 16.79 5.46 8.95 14.20
KM-21-48 605.2 610.7 5.5 3.54 0.45 0.19 12.7 0.05 4.00 6.55 10.40 3.63 5.95 9.45
KM-21-48 630.3 634.6 4.3 1.11 0.34 0.69 12.7 0.11 1.71 2.80 4.45 1.52 2.49 3.95
KM-21-48 685.5 696.8 11.3 0.98 0.05 0.06 4.2 0.02 1.07 1.75 2.77 0.98 1.60 2.54
KM-21-48 715.1 718.4 3.4 2.08 0.04 0.03 4.3 0.01 2.15 3.52 5.59 1.98 3.25 5.16
KM-21-48 723.0 724.5 1.5 1.54 0.07 0.06 4.0 0.02 1.64 2.68 4.26 1.51 2.47 3.92
KM-21-48 735.5 743.6 8.1 0.34 0.60 1.52 9.2 0.07 1.38 2.26 3.59 1.18 1.93 3.06
KM-21-48A 538.0 539.5 1.5 0.31 1.17 2.79 29.0 0.52 2.44 4.01 6.36 2.05 3.35 5.32
KM-21-48A 687.9 696.9 9.0 1.64 0.36 0.79 7.9 0.01 2.23 3.66 5.80 2.01 3.29 5.22
including 687.9 688.8 0.9 0.15 1.53 5.35 5.0 0.01 3.18 5.21 8.27 2.71 4.45 7.06
including 694.9 696.0 1.1 8.36 0.80 0.10 40.0 0.03 9.21 15.10 23.96 8.39 13.75 21.81
KM-21-49 lost hole



The true width of mineralization is estimated to be 50% to 99% of reported core width, with an average of 76%. (2) Assumptions used in USD for the copper and gold metal equivalent calculations were metal prices of $4.63/lb Copper, $1937/oz Gold, $25/oz Silver, $1.78/lb Zinc, and $1.02/lb Pb. Assumed metal recoveries (rec.), based on a preliminary review of historic data by SRK and ProcessIQ1, were 93% for copper, 92% for zinc, 90% for lead, 72% silver, and 70% for gold. The following equation was used to calculate copper equivalence: CuEq = Copper (%) (93% rec.) + (Gold (g/t) x 0.61)(72% rec.) + (Silver (g/t) x 0.0079)(72% rec.) + (Zinc (%) x 0.3844)(93% rec.) +(Lead (%) x 0.2203)(93% rec.). The following equation was used to calculate gold equivalence: AuEq = Gold (g/t)(72% rec.) + (Copper (%) x 1.638)(93% rec.) + (Silver (g/t) x 0.01291)(72% rec.) + (Zinc (%) x 0.6299)(93% rec.) +(Lead (%) x 0.3609)(93% rec.). Analyzed metal equivalent calculations are reported for illustrative purposes only. The metal chosen for reporting on an equivalent basis is the one that contributes the most dollar value after accounting for assumed recoveries.



Table 3. Full results to date of Phase 2 Drill Program at the Kay Mine Deposit, Yavapai County, Arizona. See Table 2 for width and metal equivalency notes.



Analyzed Grade Analyzed Metal Equivalent Metal Equivalent
Hole ID From m To m Length m Cu % Au g/t Zn % Ag g/t Pb % Cu eq % Au eq g/t Zn eq% Cu eq % Au eq g/t Zn eq%
KM-21-50 489.5 501.9 12.3 0.98 2.30 6.36 111.9 1.24 5.99 9.81 15.57 5.02 8.24 13.07
including 489.5 493.0 3.4 2.64 3.59 9.49 207.7 1.65 10.49 17.20 27.30 8.86 14.52 23.05
KM-21-50 509.0 562.1 53.1 0.44 0.84 1.28 35.8 0.27 1.79 2.93 4.65 1.48 2.42 3.84
including 538.1 545.6 7.5 0.28 1.94 2.62 112.8 0.82 3.55 5.81 9.23 2.82 4.63 7.34
KM-21-51B 860.5 870.2 9.8 3.00 0.13 0.10 6.5 0.05 3.18 5.21 8.27 2.93 4.80 7.62
including 864.7 865.6 0.9 8.70 0.09 0.09 16.0 0.10 8.93 14.64 23.24 8.27 13.55 21.51
KM-21-51B 881.5 884.2 2.7 0.52 0.22 0.62 28.3 0.14 1.15 1.88 2.98 0.99 1.61 2.56
KM-21-51B 893.7 903.4 9.8 1.51 0.10 0.06 4.4 0.01 1.63 2.67 4.24 1.49 2.45 3.89
including 898.2 899.3 1.1 6.56 0.11 0.10 15.0 0.04 6.79 11.13 17.67 6.28 10.29 16.32
KM-21-52 751.5 758.2 6.7 1.18 0.66 0.98 18.2 0.14 2.14 3.50 5.56 1.86 3.05 4.84
KM-21-52 787.5 789.6 2.1 0.04 1.27 1.68 28.5 0.22 1.73 2.84 4.50 1.38 2.25 3.58
KM-21-52A 763.7 793.1 29.4 0.25 1.12 1.36 51.6 0.47 1.97 3.22 5.11 1.58 2.58 4.10
including 763.7 764.9 1.2 0.38 3.01 8.69 132.0 1.68 6.97 11.43 18.13 5.80 9.50 15.08
including 771.8 774.5 2.7 1.39 2.46 4.59 116.4 1.82 5.98 9.81 15.56 5.00 8.19 12.99
including 781.5 787.6 6.1 0.31 2.63 1.64 119.5 0.65 3.64 5.97 9.47 2.81 4.60 7.30
KM-21-52A 801.3 802.5 1.2 0.42 0.90 1.29 82.0 0.17 2.15 3.52 5.59 1.73 2.83 4.50
KM-21-52A 818.8 820.2 1.4 0.39 1.62 1.29 188.0 0.36 3.45 5.65 8.96 2.66 4.35 6.91
KM-21-52A 831.2 852.4 21.2 0.05 0.91 0.80 27.2 0.29 1.19 1.95 3.10 0.93 1.52 2.42
including 837.0 841.6 4.6 0.03 2.16 1.34 69.0 0.79 2.59 4.24 6.73 1.98 3.24 5.14
KM-21-55 302.7 308.5 5.8 0.66 0.44 0.53 15.8 0.10 1.28 2.10 3.33 1.10 1.80 2.86
KM-21-56 434.6 435.9 1.2 1.53 0.39 0.13 19.0 0.01 1.97 3.23 5.12 1.75 2.86 4.54
KM-21-56 499.1 501.5 2.4 1.53 0.18 7.15 6.4 0.02 4.45 7.29 11.57 4.07 6.68 10.59
including 499.1 500.2 1.1 1.97 0.31 14.55 7.0 0.02 7.81 12.81 20.33 7.16 11.73 18.61
KM-21-56 524.0 525.0 1.1 0.97 0.12 0.07 5.0 0.03 1.12 1.83 2.91 1.01 1.66 2.64
KM-21-56 558.2 563.6 5.3 0.82 0.99 3.09 27.0 0.06 2.84 4.65 7.38 2.44 4.00 6.35
KM-21-56 577.0 578.2 1.2 0.02 1.66 0.47 5.0 0.02 1.26 2.06 3.27 0.92 1.52 2.41
KM-21-57 776.5 784.3 7.8 0.26 2.30 2.59 57.9 0.68 3.27 5.36 8.51 2.61 4.28 6.79
including 777.8 778.8 0.9 0.25 6.62 11.45 105.0 3.33 10.26 16.81 26.68 8.37 13.72 21.77
KM-21-57 819.9 835.5 15.5 1.29 2.17 2.58 90.9 0.27 4.39 7.19 11.41 3.61 5.92 9.40
including 824.0 827.5 3.5 3.69 4.67 3.81 228.5 0.29 9.88 16.19 25.69 8.13 13.33 21.15
KM-21-57 852.5 853.6 1.1 0.30 3.10 2.33 92.0 0.57 3.94 6.46 10.25 3.06 5.02 7.97
KM-21-57A 728.6 735.5 6.9 2.49 1.04 0.57 6.6 0.02 3.40 5.57 8.84 3.00 4.92 7.81
KM-21-57A 759.6 821.4 61.9 1.08 2.60 3.73 32.0 0.50 4.46 7.31 11.60 3.71 6.08 9.65
including 762.3 783.3 21.0 0.42 6.78 9.49 67.9 0.49 8.84 14.50 23.00 7.12 11.67 18.52
KM-22-57B 736.7 862.0 125.3 1.41 0.83 1.27 12.4 0.13 2.53 4.14 6.57 2.21 3.62 5.74
including 739.7 741.6 1.8 9.42 2.37 0.32 8.5 0.03 11.06 18.12 28.76 9.93 16.28 25.84
including 798.3 805.6 7.3 6.35 0.81 3.76 19.5 0.14 8.47 13.89 22.04 7.72 12.65 20.08
KM-22-57C 784.3 885.1 100.9 1.24 1.54 1.56 25.8 0.14 3.02 4.95 7.85 2.54 4.16 6.61
including 829.4 837.9 8.5 1.60 7.71 9.04 100.9 0.35 10.66 17.47 27.72 8.62 14.14 22.43
including 852.2 857.6 5.3 6.81 0.10 0.09 23.3 0.02 7.10 11.63 18.46 6.55 10.73 17.03
KM-21-58 577.0 586.4 9.4 0.43 1.28 2.48 41.3 0.47 2.59 4.25 6.74 2.15 3.52 5.59
KM-21-58 614.2 682.6 68.4 1.30 3.42 3.85 47.2 0.50 5.35 8.78 13.93 4.40 7.22 11.45
including 640.7 648.0 7.3 0.79 4.34 10.20 51.9 0.56 7.90 12.94 20.54 6.60 10.83 17.18
including 668.1 678.6 10.5 5.30 12.19 6.67 194.7 1.88 17.26 28.30 44.90 13.98 22.92 36.37
including 668.1 669.6 1.5 2.55 43.20 7.76 856.0 0.80 38.86 63.69 101.08 28.62 46.90 74.43
KM-21-58A 569.4 641.8 72.5 1.12 1.00 2.84 18.1 0.33 3.03 4.97 7.89 2.64 4.32 6.86
including 584.3 591.9 7.6 0.29 1.19 6.23 4.4 0.40 3.53 5.79 9.19 3.09 5.06 8.02
including 602.3 613.3 11.0 4.02 0.11 1.38 12.6 0.40 4.80 7.88 12.50 4.42 7.25 11.51
including 630.3 630.9 0.7 1.14 6.35 11.20 356.0 0.65 12.28 20.13 31.95 9.89 16.21 25.73
including 633.5 641.8 8.3 1.53 2.33 5.12 26.5 0.36 5.20 8.53 13.53 4.45 7.29 11.56
KM-21-58A 665.5 676.0 10.5 0.12 2.90 3.88 167.5 1.92 5.13 8.41 13.34 4.06 6.65 10.55
including 672.5 676.0 3.5 0.12 6.89 6.40 332.0 3.81 10.26 16.82 26.70 7.98 13.07 20.74
including 673.6 674.5 0.9 0.28 19.65 12.65 844.0 10.20 26.07 42.74 67.82 19.97 32.73 51.94
KM-21-58B 543.2 627.6 84.4 1.05 2.38 3.44 23.8 0.55 4.13 6.77 10.75 3.45 5.66 8.98
including 571.2 582.5 11.3 0.51 5.27 9.96 35.4 1.52 8.18 13.40 21.27 6.76 11.08 17.58
including 605.3 622.7 17.4 3.20 6.19 4.18 40.9 0.22 8.96 14.69 23.31 7.38 12.09 19.19
including 609.6 612.0 2.4 1.45 17.73 7.97 82.5 0.44 16.08 26.35 41.81 12.29 20.15 31.97
KM-22-59A 903.7 905.9 2.1 0.61 0.10 0.65 10.3 0.10 1.02 1.68 2.66 0.92 1.50 2.38
KM-22-60 554.7 648.0 93.3 1.36 5.65 3.25 32.6 0.34 6.39 10.47 16.62 5.08 8.32 13.21
including 591.6 597.7 6.1 0.58 5.62 12.00 56.3 1.40 9.37 15.37 24.38 7.78 12.75 20.24
including 627.0 644.5 17.5 5.22 25.37 4.71 100.6 0.59 23.44 38.42 60.98 18.05 29.59 46.95
including 634.3 635.5 1.2 5.63 273.00 0.18 715.0 0.28 177.99 291.74 462.98 126.03 206.57 327.82
KM-22-61 560.8 580.0 19.2 0.72 0.20 0.69 7.0 0.06 1.18 1.93 3.07 1.05 1.73 2.74
KM-22-62 636.6 682.8 46.2 0.22 1.47 3.22 53.5 0.47 2.89 4.73 7.51 2.37 3.89 6.18
including 644.4 646.2 1.8 0.89 4.36 19.26 133.0 0.77 12.18 19.96 31.68 10.41 17.07 27.09
including 650.7 657.5 6.8 0.34 3.21 9.59 145.2 1.79 7.53 12.34 19.59 6.26 10.26 16.29
including 663.2 665.5 2.3 0.53 8.66 7.82 181.6 1.55 10.60 17.38 27.58 8.30 13.61 21.60
KM-22-62 704.1 706.2 2.1 0.36 2.88 3.33 61.5 0.46 3.99 6.53 10.37 3.18 5.22 8.28
KM-22-62A 582.2 643.6 61.4 0.31 1.27 2.65 40.8 0.58 2.55 4.18 6.64 2.11 3.47 5.50
including 593.1 602.4 9.3 1.15 2.29 4.37 52.4 0.91 4.85 7.94 12.60 4.08 6.68 10.60
including 608.9 617.8 8.8 0.20 1.79 4.26 91.2 1.15 3.90 6.40 10.15 3.20 5.25 8.33
including 627.7 630.9 3.2 0.41 7.10 15.01 180.0 2.77 12.56 20.58 32.66 10.31 16.89 26.81
KM-22-62A 653.8 660.5 6.7 0.26 1.69 2.58 90.4 0.75 3.17 5.19 8.24 2.54 4.17 6.61
KM-22-62B 590.9 599.4 8.5 1.48 0.47 1.04 21.6 0.27 2.39 3.92 6.23 2.12 3.47 5.51
KM-22-62B 606.2 629.0 22.7 0.20 1.05 1.77 21.2 0.23 1.75 2.86 4.54 1.43 2.35 3.73
including 623.8 629.0 5.2 0.21 3.61 6.52 56.6 0.81 5.55 9.09 14.43 4.53 7.42 11.78
KM-22-62C 613.6 630.3 16.8 0.57 0.40 0.48 20.5 0.11 1.18 1.94 3.07 1.01 1.65 2.62
KM-22-62C 638.3 653.8 15.5 0.25 2.34 3.34 34.8 0.34 3.31 5.43 8.62 2.68 4.39 6.97
including 648.5 653.8 5.3 0.32 4.21 6.57 74.7 0.73 6.18 10.12 16.06 5.00 8.19 13.00
KM-22-63 982.2 983.1 0.9 3.41 1.23 2.19 47.0 0.24 5.43 8.90 14.12 4.79 7.85 12.45
KM-22-63A no significant assays
KM-22-63B 890.3 891.8 1.5 0.10 0.47 0.43 15.0 0.08 0.68 1.12 1.77 0.54 0.89 1.41
KM-22-63C no significant assays
KM-22-63D no significant assays
KM-22-64 317.4 325.5 8.1 1.13 0.09 2.30 14.3 0.08 2.20 3.60 5.72 2.00 3.27 5.20
KM-22-65 334.4 337.1 2.7 1.39 0.06 0.34 7.0 0.03 1.62 2.65 4.21 1.48 2.43 3.86
KM-22-66 384.4 414.8 30.5 1.00 0.11 0.09 3.0 0.01 1.13 1.85 2.94 1.03 1.69 2.68
KM-22-67 340.2 345.9 5.8 0.38 0.06 0.55 4.4 0.09 0.69 1.13 1.79 0.62 1.02 1.61
KM-22-68 407.2 408.7 1.5 1.71 0.49 0.08 8.4 0.06 2.11 3.46 5.49 1.88 3.08 4.89
KM-22-68 435.9 446.5 10.7 0.54 0.18 0.29 4.3 0.04 0.80 1.31 2.08 0.71 1.17 1.85
KM-22-69 342.0 343.6 1.6 1.19 0.87 0.96 25.7 0.06 2.30 3.78 5.99 1.97 3.24 5.14
KM-22-70 lost hole
KM-22-71 631.2 648.5 17.3 0.53 0.16 0.21 9.6 0.01 0.78 1.28 2.03 0.69 1.12 1.78
KM-22-71 657.8 668.6 10.8 3.18 0.35 0.16 22.6 0.01 3.64 5.96 9.46 3.29 5.40 8.57
including 657.8 661.4 3.7 6.75 0.28 0.09 30.9 0.02 7.20 11.81 18.74 6.61 10.83 17.19
KM-22-71A 554.3 561.4 7.2 0.39 0.22 0.64 10.3 0.22 0.90 1.47 2.34 0.78 1.29 2.04
KM-22-72 637.6 660.2 22.6 0.34 0.38 1.15 13.0 0.27 1.18 1.93 3.06 1.01 1.66 2.63
KM-22-72 669.3 671.3 2.0 0.17 2.15 4.15 23.1 0.56 3.38 5.55 8.80 2.79 4.57 7.25
KM-22-73 no significant assays
KM-22-74 649.2 688.2 39.0 0.40 1.77 3.39 30.5 0.32 3.09 5.07 8.05 2.56 4.20 6.67
including 652.6 659.8 7.2 0.68 2.57 5.13 18.0 0.11 4.39 7.19 11.42 3.67 6.02 9.55
including 678.5 688.2 9.8 0.15 3.08 5.67 32.0 0.51 4.57 7.50 11.90 3.74 6.13 9.73
KM-22-74 716.3 719.6 3.4 0.03 0.84 2.65 37.5 0.57 1.99 3.26 5.17 1.65 2.71 4.30
KM-22-75 690.7 692.8 2.1 0.23 0.25 0.84 9.3 0.22 0.83 1.36 2.15 0.71 1.17 1.86
KM-22-75 705.0 716.9 11.9 0.67 0.17 0.30 8.0 0.05 0.97 1.58 2.51 0.86 1.41 2.24
KM-22-75 723.1 731.7 8.5 0.31 0.50 1.27 11.6 0.09 1.21 1.99 3.16 1.03 1.69 2.69
KM-22-75 753.5 754.5 1.1 0.23 1.22 1.85 12.0 0.04 1.78 2.92 4.64 1.46 2.39 3.80
KM-22-76 no significant assays
KM-22-77 no significant assays
KM-22-78 no significant assays
KM-22-79 667.8 673.8 5.9 0.11 0.52 1.03 6.9 0.23 0.93 1.52 2.42 0.77 1.27 2.02
KM-22-79 681.8 689.8 7.9 2.12 1.38 3.14 47.2 0.27 4.61 7.55 11.98 4.00 6.55 10.40
KM-22-80 672.8 678.5 5.6 0.35 0.59 0.68 4.9 0.02 1.02 1.67 2.65 0.85 1.40 2.22
KM-22-80 702.9 705.9 3.0 0.13 0.04 0.99 1.0 0.01 0.54 0.89 1.41 0.49 0.81 1.28
KM-22-81 813.8 822.4 8.5 0.10 0.22 0.69 15.5 0.11 0.65 1.07 1.69 0.54 0.89 1.42
KM-22-81A 847.7 852.8 5.2 0.03 0.19 2.04 46.2 0.48 1.40 2.29 3.64 1.19 1.94 3.09
KM-22-81B 801.8 805.6 3.8 9.60 1.81 1.83 44.6 0.23 11.81 19.36 30.72 10.65 17.45 27.70
including 802.7 804.2 1.5 14.80 2.75 2.06 53.0 0.28 17.75 29.10 46.18 16.03 26.27 41.69
KM-22-81B 815.0 816.0 0.9 0.93 0.56 0.49 28.0 0.21 1.72 2.82 4.48 1.47 2.41 3.83
KM-22-81B 821.6 823.0 1.4 0.02 0.03 1.92 28.0 0.40 1.09 1.78 2.83 0.95 1.56 2.47
KM-22-81B 836.5 837.3 0.8 0.05 0.74 0.69 15.0 0.46 0.99 1.62 2.57 0.79 1.29 2.04
KM-22-81C 751.5 754.7 3.2 1.14 0.43 0.56 19.6 0.07 1.79 2.94 4.66 1.57 2.57 4.08
KM-22-81C 775.9 784.0 8.1 0.21 0.13 1.01 18.8 0.22 0.88 1.44 2.29 0.76 1.25 1.99
KM-22-81C 787.0 788.5 1.5 0.03 2.02 1.80 30.0 0.39 2.27 3.73 5.92 1.77 2.91 4.61
KM-22-82 226.5 228.0 1.5 0.14 0.07 1.58 5.4 0.53 0.95 1.55 2.46 0.85 1.40 2.22
KM-22-82 301.8 304.2 2.4 1.18 0.37 0.13 2.6 0.02 1.48 2.42 3.84 1.32 2.16 3.42
KM-22-83 no significant assays
KM-22-84 no significant assays
KM-22-85 no significant assays
KM-22-86 lost hole
KM-22-86A 545.9 546.6 0.7 0.14 0.51 0.14 16.0 0.26 0.69 1.14 1.80 0.54 0.89 1.41
KM-22-86A 563.7 564.8 1.1 0.04 1.11 0.05 13.0 0.11 0.86 1.42 2.25 0.63 1.03 1.63
KM-22-86A 565.6 566.7 1.1 0.05 0.15 0.92 25.9 0.43 0.80 1.30 2.07 0.67 1.10 1.74
KM-22-87 339.9 348.1 8.2 0.29 0.31 0.23 2.0 0.01 0.59 0.96 1.53 0.50 0.82 1.30
including 339.9 340.5 0.6 1.89 0.09 0.04 4.0 0.02 1.99 3.26 5.17 1.83 3.00 4.76
KM-22-88 344.7 345.6 0.9 2.84 0.07 0.06 2.0 0.02 2.93 4.80 7.61 2.71 4.44 7.04
KM-22-89 447.1 448.5 1.4 1.09 0.29 0.06 5.8 0.11 1.36 2.23 3.53 1.21 1.99 3.15
KM-22-90 no significant assays
KM-22-91 399.3 401.1 1.8 0.72 0.66 0.20 3.5 0.02 1.23 2.02 3.21 1.05 1.72 2.73
KM-22-92 no significant assays
KM-22-93 478.7 483.3 4.5 1.85 0.03 0.02 4.6 0.00 1.91 3.13 4.97 1.77 2.90 4.60
KM-22-93 506.6 508.6 2.0 1.63 0.01 0.01 2.2 0.00 1.66 2.72 4.32 1.54 2.52 4.01
KM-22-93 522.4 527.0 4.6 0.85 0.05 0.02 2.6 0.00 0.90 1.48 2.35 0.83 1.36 2.16
KM-22-93 615.1 616.3 1.2 2.85 0.04 0.06 5.0 0.00 2.94 4.81 7.64 2.72 4.45 7.07
KM-22-94 797.4 815.0 17.7 0.73 0.04 0.06 3.1 0.01 0.81 1.33 2.11 0.74 1.22 1.93
including 797.4 798.7 1.4 1.43 0.03 0.02 3.7 0.02 1.49 2.44 3.87 1.37 2.25 3.58
KM-22-94 829.4 832.6 3.2 0.54 0.75 0.48 6.9 0.06 1.25 2.05 3.26 1.05 1.71 2.72
KM-22-94 854.5 855.8 1.3 0.76 0.09 0.02 2.0 0.00 0.84 1.37 2.18 0.76 1.25 1.99
KM-22-94A 829.1 832.4 3.4 2.18 0.03 0.07 5.2 0.05 2.27 3.73 5.91 2.10 3.44 5.47
including 829.1 829.7 0.6 9.43 0.10 0.27 22.0 0.23 9.82 16.09 25.54 9.08 14.88 23.61
KM-22-94A 850.1 853.4 3.4 0.63 0.11 0.02 2.4 0.02 0.73 1.20 1.90 0.66 1.08 1.71
KM-22-94A 858.9 864.9 5.9 0.62 0.02 0.02 2.3 0.01 0.67 1.09 1.74 0.61 1.01 1.60
KM-22-94A 871.9 882.2 10.4 1.21 0.09 0.05 3.6 0.01 1.31 2.15 3.42 1.20 1.97 3.13
KM-22-95 432.8 435.6 2.7 0.22 0.12 0.61 4.1 0.02 0.57 0.94 1.48 0.50 0.83 1.31
KM-22-96 no significant assays
KM-23-97 512.2 521.0 8.8 2.87 2.24 2.65 27.7 0.31 5.54 9.08 14.41 4.78 7.83 12.43
including 516.1 517.7 1.6 8.12 3.67 2.33 61.2 0.14 11.76 19.28 30.60 10.31 16.91 26.83
including 516.8 517.2 0.4 17.10 4.59 0.40 59.0 0.08 20.54 33.67 53.43 18.36 30.09 47.75
KM-23-97 595.3 596.8 1.5 0.95 0.80 0.03 9.0 0.01 1.52 2.50 3.97 1.29 2.11 3.36
KM-23-98 255.7 258.8 3.0 0.53 0.13 0.11 3.5 0.01 0.69 1.12 1.78 0.61 1.00 1.59
KM-23-98 312.4 317.0 4.6 0.70 0.06 0.13 4.1 0.02 0.82 1.35 2.14 0.75 1.23 1.95
KM-23-98 342.9 347.2 4.3 0.75 0.33 0.06 3.3 0.00 1.00 1.64 2.60 0.88 1.44 2.28
KM-23-99 459.8 462.8 3.0 0.61 0.28 0.44 7.0 0.09 1.02 1.67 2.65 0.90 1.47 2.33
KM-23-99 508.3 517.9 9.6 0.04 0.59 0.74 2.0 0.03 0.70 1.15 1.82 0.56 0.92 1.47



Table 4. Results of Phase 1 Drill Program at the Kay Mine Deposit, Yavapai County, Arizona. The true width of mineralization is estimated to be 50% to 99% of reported core width, with an average of 80%.



Analyzed Grade Analyzed Metal Equivalent
Hole ID From m To m Length m Cu % Au g/t Zn % Ag g/t Pb % Cu eq % Au eq g/t Zn eq%
KM-20-01 275.8 281.5 5.6 0.57 0.48 1.20 11.6 0.18 1.70 1.61 4.51
including 275.8 276.5 0.6 0.50 1.22 5.04 32.0 0.73 4.23 4.01 11.22
including 279.8 281.5 1.6 1.21 0.98 1.49 22.6 0.23 3.10 2.94 8.22
KM-20-02 297.8 300.8 3.0 0.77 0.20 0.04 1.4 0.01 1.01 0.96 2.69
KM-20-03 256.3 259.1 2.7 3.40 1.01 0.65 69.6 0.09 5.41 5.13 14.35
including 256.3 257.3 0.9 7.42 1.79 1.11 56.0 0.17 10.32 9.78 27.37
KM-20-03 292.2 292.6 0.5 2.43 0.19 0.15 2.0 0.04 2.72 2.57 7.20
KM-20-03 295.4 295.8 0.5 1.35 0.80 0.91 6.0 0.06 2.61 2.47 6.92
KM-20-03A 252.4 256.9 4.6 3.70 2.55 0.27 35.6 0.03 6.85 6.49 18.15
including 252.4 253.1 0.8 9.74 6.34 0.40 164.0 0.11 18.19 17.24 48.23
KM-20-05 266.6 269.0 2.4 6.47 1.94 0.57 43.3 0.14 9.19 8.71 24.37
including 266.6 267.8 1.2 10.60 2.21 1.05 50.0 0.26 13.89 13.16 36.83
KM-20-06 267.9 281.5 13.5 1.02 0.85 1.23 45.6 0.30 2.92 2.77 7.75
including 267.9 268.4 0.5 1.54 2.20 6.10 31.0 0.81 6.73 6.38 17.85
including 276.6 281.5 4.9 1.86 0.87 1.96 92.1 0.42 4.54 4.30 12.04
including 280.0 281.0 1.1 3.22 1.03 0.64 340.0 0.04 7.82 7.41 20.74
KM-20-08 abandoned, off target
KM-20-09 588.1 588.4 0.3 0.91 1.74 1.86 15.0 0.40 3.72 3.52 9.86
KM-20-09 613.4 614.1 0.7 0.90 1.81 1.04 10.0 0.08 3.32 3.15 8.81
KM-20-09 614.6 614.9 0.3 2.64 0.36 0.98 19.0 0.10 3.60 3.41 9.54
KM-20-09 632.8 638.9 6.1 0.12 4.18 8.02 41.7 0.82 8.23 7.80 21.83
including 633.6 637.9 4.4 0.15 5.46 9.06 33.1 0.50 9.81 9.29 26.00
including 636.9 637.9 1.1 0.17 9.77 14.65 68.0 0.78 16.92 16.03 44.86
KM-20-10 563.6 568.5 4.9 2.39 2.16 3.27 24.9 0.31 6.24 5.92 16.55
including 563.6 566.6 3.0 3.66 2.42 3.16 28.2 0.32 7.78 7.38 20.64
including 567.2 568.5 1.2 0.33 2.52 5.10 28.4 0.43 5.33 5.05 14.12
KM-20-10 574.2 574.9 0.6 0.12 4.33 11.30 113.0 0.16 10.09 9.56 26.75
KM-20-10 577.7 579.3 1.6 0.03 0.70 4.38 45.9 0.68 3.09 2.93 8.20
KM-20-10 582.3 583.1 0.8 0.03 0.42 2.90 51.0 1.07 2.42 2.29 6.40
KM-20-10A 521.2 522.5 1.3 2.13 1.27 7.46 51.1 0.91 7.07 6.70 18.75
KM-20-10A 527.9 538.6 10.7 1.32 1.66 2.58 27.2 0.30 4.40 4.17 11.66
including 527.9 529.4 1.5 6.69 0.92 1.62 30.2 0.07 8.59 8.14 22.77
including 532.2 535.3 3.1 0.72 1.75 2.99 34.3 0.42 4.17 3.95 11.07
including 537.2 538.6 1.4 0.16 7.29 9.06 79.2 0.60 12.24 11.60 32.44
KM-20-10B 503.0 530.7 27.6 0.87 0.97 1.76 21.3 0.32 2.87 2.72 7.61
including 503.0 509.6 6.6 1.78 1.55 2.55 29.8 0.37 4.79 4.54 12.70
including 513.9 518.3 4.4 1.08 1.89 4.05 47.4 0.68 5.29 5.01 14.02
including 527.2 530.7 3.5 1.91 2.32 3.93 52.9 0.99 6.68 6.33 17.72
KM-20-10C 523.9 530.7 6.8 0.58 3.32 5.84 102.0 1.15 7.65 7.25 20.28
including 523.9 528.2 4.3 0.88 4.89 7.61 125.2 1.45 10.60 10.05 28.11
including 525.6 526.4 0.8 0.52 16.65 21.40 214.0 2.76 29.15 27.62 77.29
KM-20-11 554.1 556.9 2.7 4.14 2.83 3.56 70.0 0.28 9.23 8.75 24.48
KM-20-12 371.9 376.7 4.9 3.99 0.37 0.62 12.4 0.07 4.76 4.51 12.61
including 371.9 373.7 1.9 8.49 0.67 1.53 28.0 0.16 10.10 9.57 26.77
KM-20-12 379.5 404.2 25.9 0.73 0.08 0.08 2.3 0.01 0.87 0.82 2.30
KM-20-13 443.6 486.8 43.1 1.68 1.26 1.67 23.3 0.24 3.94 3.73 10.45
including 444.4 459.6 15.2 3.42 1.80 2.36 38.5 0.39 6.71 6.36 17.80
including 444.4 447.1 2.7 1.02 3.74 10.64 55.0 1.88 10.14 9.61 26.89
including 451.4 455.8 4.4 8.41 1.18 0.16 65.3 0.02 10.34 9.80 27.42
KM-20-14 421.7 461.6 39.9 1.47 1.00 1.67 18.4 0.19 3.40 3.22 9.00
including 426.3 429.8 3.5 9.56 1.28 0.95 30.0 0.07 11.58 10.98 30.71
including 457.2 460.7 3.5 0.36 2.58 8.33 26.3 0.38 6.61 6.26 17.52
KM-20-14A 404.6 409.0 4.4 1.67 1.48 2.50 79.2 0.41 5.07 4.80 13.44
including 404.6 406.4 1.7 4.08 2.46 5.02 173.6 0.53 10.41 9.87 27.61
KM-20-14A 421.0 443.5 22.5 0.86 0.72 1.51 15.9 0.18 2.41 2.28 6.38
including 421.0 421.8 0.8 9.81 2.91 1.69 45.0 0.19 14.01 13.28 37.15
including 421.0 425.0 4.1 3.23 1.14 1.30 21.4 0.14 5.17 4.90 13.71
KM-20-15 506.8 510.1 3.3 0.05 0.33 3.73 192.0 1.75 4.24 4.02 11.25
KM-20-16 480.4 518.8 38.4 0.85 0.81 2.24 24.3 0.25 2.87 2.72 7.61
including 480.4 492.9 12.5 1.63 1.98 4.23 48.5 0.50 5.95 5.64 15.78
including 480.4 483.4 3.0 2.40 4.74 7.49 77.9 0.91 11.29 10.70 29.93
including 489.8 492.9 3.0 3.61 2.59 6.90 100.7 0.92 10.22 9.68 27.10





About Arizona Metals Corp



Arizona Metals Corp owns 100% of the Kay Mine Project in Yavapai County, which is located on a combination of patented and BLM claims totaling 1,300 acres that are not subject to any royalties. An historic estimate by Exxon Minerals in 1982 reported a “proven and probable reserve of 6.4 million short tons at a grade of 2.2% copper, 2.8 g/t gold, 3.03% zinc, and 55 g/t silver.” (Fellows, M.L., 1982, Kay Mine massive sulfide deposit: Internal report prepared for Exxon Minerals Company, November 1982, 29 p.) The historic estimate at the Kay Mine Deposit was reported by Exxon Minerals in 1982. The historic estimate has not been verified as a current mineral resource. None of the key assumptions, parameters, and methods used to prepare the historic estimate were reported, and no resource categories were used. Significant data compilation, re-drilling and data verification may be required by a “qualified person” (as defined in National Instrument 43-101 – Standards of Disclosure for Mineral Projects) before the historic estimate can be verified and upgraded to be a current mineral resource. A qualified person has not done sufficient work to classify it as a current mineral resource, and Arizona Metals is not treating the historic estimate as a current mineral resource.



The Kay Mine Deposit is a steeply dipping VMS deposit that has been defined from a depth of 60 m to at least 900 m. It is open for expansion on strike and at depth.



The Company also owns 100% of the Sugarloaf Peak Property, in La Paz County, which is located on 4,400 acres of BLM claims. Sugarloaf is a heap-leach, open-pit target and has a historic estimate of “100 million tons containing 1.5 million ounces gold” at a grade of 0.5 g/t (Dausinger, 1983, Westworld Resources).



The historic estimate at the Sugarloaf Peak Property was reported by Westworld Resources in 1983. The historic estimate has not been verified as a current mineral resource. None of the key assumptions, parameters, and methods used to prepare the historic estimate were reported, and no resource categories were used. Significant data compilation, re-drilling and data verification may be required by a qualified person before the historic estimate can be verified and upgraded to a current mineral resource. A qualified person has not done sufficient work to classify it as a current mineral resource, and Arizona Metals is not treating the historic estimate as a current mineral resource.



Qualified Person and Quality Assurance/Quality Control



All of Arizona Metals’ drill sample assay results have been independently monitored through a quality assurance/quality control protocol which includes the insertion of blind standard reference materials and blanks at regular intervals. Logging and sampling were completed at Arizona Metals’ core handling facilities located in Anthem and Black Canyon City, Arizona. Drill core was diamond sawn on site and half drill-core samples were securely transported to ALS Laboratories’ (“ALS”) sample preparation facility in Tucson, Arizona. Sample pulps were sent to ALS’s labs in Vancouver, Canada, for analysis.



Gold content was determined by fire assay of a 30-gram charge with ICP finish (ALS method Au-AA23). Silver and 32 other elements were analyzed by ICP methods with four-acid digestion (ALS method ME-ICP61a). Over-limit samples for Au, Ag, Cu, and Zn were determined by ore-grade analyses Au-GRA21, Ag-OG62, Cu-OG62, and Zn-OG62, respectively.



ALS Laboratories is independent of Arizona Metals Corp. and its Vancouver facility is ISO 17025 accredited. ALS also performed its own internal QA/QC procedures to assure the accuracy and integrity of results. Parameters for ALS’ internal and Arizona Metals’ external blind quality control samples were acceptable for the samples analyzed. Arizona Metals is not aware of any drilling, sampling, recovery, or other factors that could materially affect the accuracy or reliability of the data referred to herein.



The qualified person who reviewed and approved the technical disclosure in this release is David Smith, CPG, a qualified person as defined in National Instrument43-101–Standards of Disclosure for Mineral Projects. Mr. Smith supervised the preparation of the scientific and technical information that forms the basis for this news release and has reviewed and approved the disclosure herein. Mr. Smith is the Vice-President, Exploration of the Company. Mr. Smith supervised the drill program and verified the data disclosed, including sampling, analytical and QA/QC data, underlying the technical information in this news release, including reviewing the reports of ALS, methodologies, results, and all procedures undertaken for quality assurance and quality control in a manner consistent with industry practice, and all matters were consistent and accurate according to his professional judgement. There were no limitations on the verification process.



Figure 1. Plan view of Kay project exploration targets, drill intercepts, and drill infrastructure. Hole KM-23-104, intersected a broad interval of 63 metres of sulphide-bearing core, Including 16 metres of VMS mineralization. The true width of mineralization in this area is yet to be determined. (Graphic: Business Wire)



Figure 2. Plan view displaying intercepts of VMS mineralization intersected by hole KM-23-104 on the Western Target. The true width of mineralization in this area is yet to be determined. Also shown is the proposed trace of wedge hole KM-23-104A (underway) and hole KM-23-107 from W2 pad, which shall commence shortly to test for the northern extension of the new mineralized zone. (Graphic: Business Wire)



Figure 3. Cross section of Western Target at the Kay Mine Project showing drill hole KM-23-104 which intersected 16 metres of stringer to semi-massive sulphide mineralization, including visible sphalerite and chalcopyrite mineralization. The true width of mineralization in this area is yet to be determined. Also shown is the proposed trace of wedge hole KM-23-104A, currently underway from pad W1. (Graphic: Business Wire)



Figure 4. Core from hole KM-23-104 at the Western Target, displaying stringer to semi-massive sulfide mineralization hosted in a quartz crystal-rich volcaniclastic and breccia, with sulphide mineralization including pyrite, pyrrhotite, sphalerite, and chalcopyrite. (Graphic: Business Wire)



Figure 5. Core from hole KM-23-104 (at 2,829’ downhole) at the Western Target, displaying stringer to semi-massive sulfide mineralization including stringers of sphalerite and flecks of chalcopyrite. (Graphic: Business Wire)



Posted April 12, 2023

Share this news article

MORE or "UNCATEGORIZED"


Dore Copper Confirms Copper Mineralization on its Cedar Bay Southwest Extension

Doré Copper Mining Corp. (TSX-V: DCMC) (OTCQB: DRCMF) (FRA: DCM)... READ MORE

July 24, 2024

PTX Metals Announces Successful Near Surface Drill Results from W2 Cu-Ni-PGE Project which Significantly Expanded the Mineralized Trend Outside the W2 Deposit

PTX Metals Inc. (CSE: PTX) (OTCQB: PANXF) (Frankfurt: 9PX)  is p... READ MORE

July 24, 2024

Callinex Mines Closes Oversubscribed $2.1 million Private Placement Financing

Callinex Mines Inc.  (TSX-V: CNX) (OTCQX: CLLXF) is pleased to a... READ MORE

July 24, 2024

Red Pine Confirms Independent Sampling and Assaying Validating Corrected Assay Database for Updated Resource Estimation

Red Pine Exploration Inc. (TSX-V: RPX) (OTCQB: RDEXF) reports the... READ MORE

July 24, 2024

MAG Announces Second Quarter 2024 Production From Juanicipio and Increases Grade Guidance

MAG Silver Corp. (TSX:MAG) (NYSE American: MAG) reports productio... READ MORE

July 24, 2024

Copyright 2024 The Prospector News
